SP34Millivolt · Millivolt (standing pilot)

About the SP34 Millivolt

Millivolt (standing-pilot) model: no electricity required — keeps working in a power outage. Fan kit and remote or thermostat are NOT included; add them under Optional Accessories.

As a contemporary heating solution to be installed inside a fireplace, the SP34 benefits from a wide range of design options.

The SP34 is a Stunning Direct Vent Gas Fireplace This enables customization to meet your exact specifications. Because it’s a direct vent model, it can be placed almost anywhere in the home; with flexible venting connecting it to the outside world, air is allowed to flow around the fire bin when necessary. A Traditional Gas Fireplace that Offers Excellent Energy-Efficiency Energy-efficiency is always an important consideration when selecting a suitable heating appliance. Not only does better efficiency mean lower bills, saving fuel is also environmentally important. The SP34 is rated at 70.18%/70.07% AFUE. It also performs at 20,500 BTU/hr input when using natural gas and 20,500 BTU/hr input for LP. Its high efficiency is defined as 67.14% for natural gas and 68.91% for LP gas. Overall, the SP34 makes a cost-effective and economical addition to any home. Range of Exceptional Design Features on Our Gas Fireplace The model can be tailored to meet a wide range of specifications. One of the real design advantages of this choice is the front screen – available with a standard arched or optional rectangular format, it is generously proportioned for maximum viewing pleasure. Control is achieved through a Komfort Kontrol remote that can be minutely adjusted to give the exact temperature required. Other features of the SP34 include high-low regulator, an engineer-designed burner system, and an electronic ignition.

Features

• Works when the power is out — the standing pilot needs no electricity; only the fan needs power
• Fan kit and remote/thermostat sold separately (see Optional Accessories)
• Viewing Area: 19 ¾” x 27 ¼”
• IPI and Millivolt Options
• Log Set
• Screen Front - Included
• 20,500 BTU/hr Input-NG
• 20,500 BTU/hr Input - LP
• Ceramic Glass
• Quick-Latch Glass
• Certified to ANSI Z21.88 Vented Gas Heater
• Refractory Options: Black Glass Refractory
• Overlay Options Arched Prairie Overlay
• Prairie Overlay
• Fan Kit - Optional
• Remote Options On/Off Remote Control

Will it fit?

Framing (rough opening)

34½" × 33½" × 14" (W × H × D)

Unit size

34" × 30⅞" × 13½" (W × H × D)

Vent pipe

4" × 6⅝"

Height

30"

From the manufacturer's documentation (page 16). We confirm every measurement on the site visit before anything is ordered.

Specifications

Heat output

20,500 BTU/hr (turns down to 14,000)

Heating area

~1,000 sq ft (our estimate from the BTU rating; layout and insulation vary)

Viewing area

19 3/4" x 27 1/4"

Weight

140 lbs

Documents

• 📄 English- SP Series Brochure
• 📄 English - SP34L & MV Manual
• 📄 SP34-50A Log Set R3 (Log Set Instructions)
• 📄 Vinyl Flooring and Vinyl Siding Addendum
