SP41Millivolt · Millivolt (standing pilot)

About the SP41 Millivolt

Millivolt (standing-pilot) model: no electricity required — keeps working in a power outage. Fan kit and remote or thermostat are NOT included; add them under Optional Accessories.

Slim profile direct vent fireplace with traditional log set and low clearances! The SP41 makes a cost-effective and economical addition to any home. Order now!

The SP41 is a Stunning Direct Vent Gas Fireplace As an ideal contemporary heating solution to be installed inside an existing fireplace, the SP41 benefits from a wide range of design options. This enables customization to meet your exact specifications. Because it’s a direct vent model, it can be placed almost anywhere in the home; with flexible venting connecting it to the outside world, air is allowed to flow around the fire bin when necessary. A Traditional Gas Fireplace that Offers Excellent Energy-Efficiency Energy-efficiency is always an important consideration when selecting a suitable heating appliance. Not only does better efficiency mean lower bills, saving fuel is also environmentally important. The SP41 is rated at 70.05%/70.46% AFUE. It also performs at 28,000 BTU/hr input when using natural gas and 28,000 BTU/hr input for LP. Its high efficiency is defined as 71.08% for natural gas and 71.19% for LP gas. Overall, the SP41 makes a cost-effective and economical addition to any home. Range of Exceptional Design Features on Our Gas Fireplace The model can be tailored to meet a wide range of specifications. One of the real design advantages of this choice is the front screen – available with a standard arched or optional rectangular format, it is generously proportioned for maximum viewing pleasure. Control is achieved through a Komfort Kontrol remote that can be minutely adjusted to give the exact temperature required.

Features

• Works when the power is out — the standing pilot needs no electricity; only the fan needs power
• Fan kit and remote/thermostat sold separately (see Optional Accessories)
• Log Set
• Viewing Area: 23 3/8” x 33 5/8”
• 28,000 BTU/hr Input – NG
• 28,000 BTU/hr Input – LP
• Electronic Ignition (IPI)
• Standing Pilot Ignition
• Ceramic Glass
• Fan Kit
• Remote
• Engineer Designed Burner System
• Certified to ANSI Z21.88 Vented Gas Heater
• Rectangular Standard Screen Front
• Black Glass Refractory
• Arched Prairie Design Overlay

Will it fit?

Framing (rough opening)

41" × 37" × 15½" (W × H × D)

Unit size

40¾" × 34½" × 15" (W × H × D)

Vent pipe

4" × 6⅝"

From the manufacturer's documentation (page 16). We confirm every measurement on the site visit before anything is ordered.

Specifications

Heat output

28,000 BTU/hr (turns down to 14,000)

Heating area

~1,400 sq ft (our estimate from the BTU rating; layout and insulation vary)

Viewing area

34 3/8" x 24 1/8"

Weight

179 lbs

Documents

• 📄 English- SP Series Brochure
• 📄 English - SP41L & MV Manual
• 📄 SP41-50A Log Set R3 5.21 (Log Set Instructions)
• 📄 Vinyl Flooring and Vinyl Siding Addendum
